This 2.4" Color LCD Video Inspection Camera use optoelectronic technology to investigate hard-to-reach area. It helps you to diagnose broken part, weld point and released parts easily to save time and increase productivity. The 180° Image Rotation function on receiver allows you to adjust viewing orientation.
Suitable for hard-to-reach inspection
LCD: 2.4 inch TFT Color screen with 640 x 480 resolution
Lens Sensor Resolution: 640 x 480 pixels
180° Image Rotation function
4 adjustable white LED lights for night vision
Water resistant Camera Head: IP67
F/2.8 Lens with 54°Viewable Angle
3~6 cm focal distance
6.8mm PE covered metal probe with ABS handle
Comfort Grip Housing
Conformed with CE Standard
Optional Extension Cable
|
Free Shipping, 7-9 Day Arrive
Original price: US $185.99
Now Price: US $145.99
|
It has built-in 4pcs white LED light (with Brightness Control) on camera head to illuminate the inspection area. The 1 m Flexible tube is Waterproof with 9.8mm diameter , so that you can inspect area under water, gaps and holes. Optional Extension Cable (2m/ 3 m / 5m) allows you to extend the vision of inspection point.
The tool set also comes with accessory hook, magnet and mini mirror to attach to the camera head for picking up small objects, viewing and hooking to identify the problem conveniently.
This inspection camera has many applications including HVAC inspection, vent pipe, machine equipment, engine, cable routing, automotive / boat / aircraft inspection.
Sensitivity: 0.7V (Lux. sec)
Color Mosaic: RGB Bayer Pattern
Automatic white comparison & exposure to light
Camera Illumination: 4 white LED
Camera:
Lens: F/2.8
Lens Coverage: 54°
Focal Distance: 3 ~ 6 cm
Outer diameter: 9.8 mm
IP 67 water resistant
Probe:
Metal Tube Length: 1000.0 ± 2.0 mm
Diameter of hard tube: 6.8 mm
Minimum Bending Radius: 4.5 cm
Operating Temperature: 0 ~ 45 °C
Power: 4 x 1.5V AA batteries (not included)
Power Consumption: 200 mA
Handle Length: 115 mm
Package include::
Inspection Camera
Magnet Tip; Hook Tip; Mirror Tip
English Instruction Manual
